In modern retail and commercial displays, corrugated cardboard display racks are widely used in supermarkets, convenience stores, exhibitions, and temporary promotions due to their lightweight, environmentally friendly, and economical properties.
However, with increasing environmental awareness and cost control requirements, the market and businesses are generally concerned about the following question: Can corrugated cardboard display racks be reusable?
This article will systematically and professionally address this question by focusing on the material properties, structural design, operating conditions, and maintenance methods of corrugated cardboard display racks.
What are corrugated cardboard display racks?
Corrugated cardboard display racks are used for merchandise display, primarily made of corrugated cardboard. Their core feature is their ability to balance lightweight and load-bearing properties through the unique structure of corrugated cardboard. Corrugated cardboard display racks are generally constructed from face paper, corrugated core paper, and backing paper. Through cutting, folding, splicing, or gluing processes, they form a three-dimensional, self-supporting structure capable of supporting merchandise.
Corrugated cardboard display stands have the following basic characteristics:
• Lightweight: Compared to wooden, metal, or plastic display stands, corrugated cardboard display stands are lightweight, making them easy to transport and install.
• Environmentally friendly: Cardboard is recyclable, embracing environmental sustainability.
• Economical: Low production costs make it suitable for large-scale applications and temporary promotions.
• Processability: Easy to cut, fold, print, and customize, meeting the display needs of different products and scenarios.
However, the reusability of corrugated cardboard display stands is affected by the material properties, structural strength, and the operating environment.
Material Properties and Durability of Corrugated Cardboard Display Stands
The reusability of corrugated cardboard display stands primarily depends on its material properties. Corrugated cardboard consists of a surface layer and a corrugated core, with the corrugated structure enhancing its load-bearing capacity. Depending on the number and thickness of the cardboard layers, corrugated cardboard display stands can be categorized as single-corrugated, double-corrugated, or multi-layer composite.
1. Single-wall Corrugated Cardboard
Single-wall corrugated cardboard consists of a layer of corrugated core paper sandwiched between two layers of flat cardboard, typically with a thickness of 3-5 mm. Single-wall corrugated cardboard displays are suitable for lightweight merchandise, such as small snacks, stationery, and cosmetics. However, their load-bearing capacity is limited, they are rarely reused, and they are easily damaged by weight, moisture, or friction.
2. Double-wall Corrugated Cardboard
Double-wall corrugated cardboard is a single-wall corrugated cardboard with an additional corrugated core and a surface cardboard layer. It is typically 6-10 mm thick. Double-wall corrugated cardboard displays offer significantly increased load-bearing capacity and are suitable for medium-weight merchandise, such as beverage bottles, daily necessities, or household cleaning products. Under appropriate conditions, double-wall corrugated cardboard displays can be reused multiple times.
3. Multi-layer Composite Cardboard
Multi-layer composite cardboard consists of multiple layers of corrugated cardboard stacked together, with a thickness of over 15 mm and a greater load-bearing capacity. Multi-layer corrugated cardboard displays can support heavier merchandise and offer greater structural stability, allowing for greater reuse. They are commonly used in supermarket promotions, exhibitions, and temporary events.
The durability of corrugated cardboard display stands is also affected by surface treatment. For example, lamination, spray coating, or UV printing can improve the cardboard's water and abrasion resistance, thereby extending its reusability.
Corrugated Cardboard Display Stand Structural Design and Reusability
The structural design of corrugated cardboard display stands directly impacts their reusability. The design of the frame involves multiple aspects, including the load-bearing structure, support method, shelf design, and connection method.
1. Load-Bearing Structure Design
The load-bearing structure is a key element in the reusability of corrugated cardboard display stands. Well-designed folding ribs, plug-in slots, and reinforcement plates can distribute the weight of the merchandise, reduce localized stress concentration, and minimize deformation or damage to the cardboard due to overload. The more effective the load-bearing design, the greater the reusability of the corrugated cardboard display stand.
2. Support Method
Common support methods for corrugated cardboard display stands include standalone and modular. Standalone supports utilize a base and columns for self-supporting support, while modular supports enhance stability through plug-in or modular designs. A well-designed support structure can maintain structural integrity during repeated assembly and disassembly, thereby increasing the number of reusable racks.
3. Shelf and Spacing Design
The number, thickness, and spacing of a corrugated cardboard display rack's shelves also influence its reusability. Shelf spacing must balance the display space and load-bearing capacity of the merchandise to avoid deformation caused by excessive weight or improper shelf spacing. A corrugated cardboard display rack with a well-designed shelf structure can accommodate repeated placement and movement of merchandise, extending its service life.
4. Connection Method
Corrugated cardboard display racks are commonly connected using splicing, folding, or gluing. Splicing and folding structures are suitable for multiple assembly and disassembly, facilitating reuse; gluing structures are suitable for single-use but have lower reusability. Therefore, the choice of connection method directly determines the reusability of a corrugated cardboard display rack.
Usage Conditions and Factors Influencing Reusability of Corrugated Cardboard Display Racks
The reusability of a corrugated cardboard display rack also depends on usage conditions, including load capacity, ambient humidity, handling methods, and maintenance measures.
1. Load-bearing capacity
If corrugated cardboard display racks are loaded with merchandise exceeding their designed load capacity for extended periods, they may deform, break, or cause the corrugated laminate to separate, limiting their reusability. Properly matching the weight of the merchandise with the load-bearing capacity of the rack is essential to ensuring the reusability of corrugated cardboard display racks.
2. Humidity
Cardboard is sensitive to moisture. High humidity can easily cause the cardboard to absorb moisture and swell, reducing its load-bearing capacity and structural stability. To ensure reusability, corrugated cardboard display racks should be protected from prolonged exposure to humidity or treated with moisture-resistant treatments such as lamination or coating.
3. Handling and installation
Improper handling during the handling and installation of corrugated cardboard display racks, such as squeezing, dropping, or forceful bending, can damage the cardboard and reduce its reusability. Proper handling, disassembly and transportation, and avoiding sharp impacts can effectively extend the lifespan of corrugated cardboard display racks.
4. Care and Maintenance
Regularly inspect the frame's joints, folding ribs, and load-bearing panels, and promptly repair minor damage to extend the reusability of your corrugated cardboard display stand. Also, avoid using it if the printing or lamination is damaged to maintain the frame's aesthetics and functionality.
Reusability of Corrugated Cardboard Display Stands
Based on material properties, structural design, and usage conditions, the reusability of corrugated cardboard display stands can be categorized as follows:
• Lightweight Merchandise Stands: Single-use corrugated cardboard display stands are suitable for short-term use with limited reuse, often used for temporary promotions or short-term events.
• Medium-use Merchandise Stands: Double-use corrugated cardboard display stands can be reused several to over ten times under proper usage conditions, making them suitable for mid-term merchandise displays and promotional events.
• Heavy-use Merchandise Stands: Multi-layer composite corrugated cardboard display stands feature a scientific design and a stable structure. With proper maintenance, they can be reused multiple times, meeting long-term display needs.
Furthermore, through the rational design of the plug-in structure and support method, corrugated cardboard display stands can be assembled, disassembled, and transported without damaging the frame, further increasing their reusability.
